16A Heater Rotary Switch
  • 16A Heater Rotary Switch16A Heater Rotary Switch
  • 16A Heater Rotary Switch16A Heater Rotary Switch
  • 16A Heater Rotary Switch16A Heater Rotary Switch
  • 16A Heater Rotary Switch16A Heater Rotary Switch
  • 16A Heater Rotary Switch16A Heater Rotary Switch

16A Heater Rotary Switch

ELITE LEGION was set up formally in 2004, as one of the professional China rotary switch manufacturers, we are strong strength and complete management. If you need this 16A Heater Rotary Switch, please contact with us, we will provide you with good service and factory discounted prices.

Send Inquiry

Product Description

ELITE LEGION is one of the suppliers of heater rotary switches in China, and the quality has received high praise from many customers. Currently, this 16A heater rotary switch has launched multiple functions, This rotary switch is not only suitable for heaters, but also for most household appliances on the market. The material meets the UL-94V0 flame retardant standard, the iron bracket is galvanized for durability, and the electrical life can reach the standard of 10000 cycles at least. In addition to the function list below, you can also customize function according to your needs.


Product Specification Of ELITE LEGION 16A Heater Rotary Switch:

Brand

ELITE LEGION

Model

HR31 Series

Rating

16A 125/250V~50Hz T125

Rotation Angle

90°60°45°

Initial Contact Resistance

50mΩMax

Insulation Resistance

100MΩMin 500VDC

Withstand Voltage

1500VAC/Min

Electrical Life

10000 Cycles Min


Example of specification diagram for one of the features


Feature And Application Of ELITE LEGION 16A Heater Rotary Switch:

The following are the features we are currently launching. We also support customization features.

HR31 series (90°)Function:


HR31 series (60°)Function:


HR31 series (45°)Function:


In addition to being used for heaters, this 16A rotary switch is also suitable for air coolers, ovens, electric hotpots, and so on.


Details Of ELITE LEGION 16A Heater Rotary Switch:


Q&A

Q: Can you give me samples to test and how many samples?

A: Yes, we can provide free samples, with shipping and taxes paid by the buyer. Usually, free samples are 1~10 pcs.

Q: What is the delivery time?

A: 3-7 days for samples; 15-30 days for batch goods.

Q: Is there cheap shipping cost to our country?

A: For small order, express will be best,and for bulk order, shipping by sea is better, but it takes much time.

Q: What is your MOQ?

A: In general ,our MOQ is 500 pcs, it will be more convenient and safety on packaging. Of course, it can be negotiable according to your situation.

Q: Can you accept OEM or ODM?

A: Yes, we can accept OEM and ODM, but please offer your authorization certification.


Using Tips

1 When welding, any pressure applied to the terminals may cause conditions as looseness,deformation of terminals and electrical degradation.

2 For second time welding job, please proceed welding after it is recovered to room temperature. Continuous heating may cause loose off, deformation of terminals and electrical degradation.

3 When welding, water-soluble flux may causes corrosion to switches.

4 Don’t clean it with water.

5 After final assembly as a completed product, please make sure that there’s no erosion gas/materials released from peripheral parts/materials as it may causes contact failure of switches.

6 Keep it storage under normal temperature, humidity and prevent from direct sunshine,erosion gas. Products sure be used within 6 months.

7 For small quantity which taken from main packages, please keep it in plastic bags and sealed. And have it storage under up-mentioned environment.
